BMH Semi Gantry Crane

  • Capacity: 1~32t (Standard, Non-standard Customized)
  • Span: 7.5~31.5m(Max 35m) (Customized)
  • Lifting height: 6,9,12,18,24,30m (Customized)
  • Lifting speed: 0.35~8m/min(defined by Capacity)
  • Traveling speed: 20/30 m/min
  • Duty Group: ISO A3, A4
  • Protection degree: Ip54/Ip54
  • Working temperature:-20℃~+40℃
  • TAG:Gantry Crane



BMH semi gantry crane is one leg moving on the floor rails and the other running on the runway beam, and the gantry crane is a very suitable design for wide factories. The operator will only require 2 operational bays without having the need to incur a high cost to build a continuous runway beam and columns in the centre of the factory.

Now we have developed no flanges wheels which makes the semi-gantry crane moving without rails on the ground.

BMH single girder semi gantry crane

BMH single girder semi gantry crane

  • 1Reasonable structure
  • 2Strong rigidity
  • 3Semi gantry supporting legs, one side traveling on the factory supporting beam.
  • 1Main frame is one-time forming,End carriage is made by Rectangular tube
  • 2Complete welding is made by robot
  • 3Top brand motors and panels

BMH semi girder gantry crane is wiely used in Manufacturing workshop, metallurgy, petroleum,petrochemicals,ports,railway,civil aviation,power station,food industry, paper making,building material, warehouses and other material handling application.

desgin Text Installation services

Technical data

BMH semi gantry crane drawing

Capacity Ton 1 2 3 5 10 16 20 32
Span Meter 5~20 5~20 5~20 5~20 5~20 5~20 5~20 5~20
Lifting Height Meter 6~12 6~12 6~12 6~12 6~12 6~12 6~12 6~12
Lifting Speed M/min 0.8/8 0.8/8 0.8/8 0.8/8 0.7/7 0.35/3.5 7.2 7.5
Trolley Speed M/min 20/30 20/30 20/30 20/30 20/30 20/30 42.1 42.4
Crane Speed M/min 20/30 20/30 20/30 20/30 20/30 20/30 40.1 38
Working Duty A4~A5 A4~A5 A4~A5 A4~A5 A4~A5 A4~A5 A4~A5 A4~A5
Rail Type P24 P24 P24 P24/P38 P38 P38 P43/QU70 QU70

Please note: Above specification just for your reference,our crane can be customized design based on your requirements.
